CATALOGUE : Buffer / NG Stocker


- To separate / stock PCB of different grades

- To regulate rate of production line flow

- FIFO or LIFO mode available



Features

  • Suitable for SMT, ICT Auto and Manual Insertion lines

  • Choice of LCD Touch Screen or Operator Panel

  • Configurable through the Operator Panel

  • Programmable Logic Control

  • Power failure and abnormal condition recovery

  • Upper and lower clamps for positive magazine location

  • Regulated pusher force

  • SMEMA interface for communication between machines

  • Available in other conveying mediums e.g. Flatbelt, polycord

Stocker Dimensions (mm)/
Weight (approximate in kg)



A

B

C

D

W

Weight(S2)

( M ) series

1270

1300

500

160

50 to 250

190

( L ) series

1600

1300

650

160

50 to x

210

x - Depending on magazine size















Machine Specifications

Cycle time

6 secs

Magazine pitch

10 to 100mm (in steps of 10mm)

Offset pitch

Top and bottom magazine pitch configurable through the operator panel

Reference side

Front or rear as specified

Electrical requirement

230VA max (voltage as specified)

Optional Items

Tower light
Push-Button  / Touch Screen Panel
Other sizes available
